Automated regression testing DOS programs with DOSBox-X

Developing for retro platforms like DOS doesn’t mean you have to abandon modern development practices. In this post, I’ll share how to implement a robust end-to-end regression testing for DOS programs, eg. tools or games. There’s also some code [git].

Bill of materials

Ubuntu Desktop 24.04 (other distros probably work as well)
awk, bash (should be installed by default)
Dosbox-x (I used the flatpak installation, pick whatever works for you)
Imagemagick
xdotool

The Goal

We want to automatically run our program inside an emulator, simulate user input, capture the visual output, and verify it against a known “good” reference image. This ensures that recent code changes haven’t broken the rendering or game logic.

1. The Configuration: `dosbox-test.conf`

First, we need a specific DOSBox-X configuration for testing. This ensures a consistent environment (CPU speed, graphics mode, file system) every time we run the tests.

Key settings to include:

[sdl]
# Run in windowed mode so xdotool can find it
fullscreen = false
titlebar = MyGame-Test

[dosbox]
# Where screenshots will be saved
captures = target/screenshots
# Ensure consistent machine type
machine = ega

[autoexec]
# Mount your build directory as C:
mount c ./target
# Mount a directory for logs if needed
mount d ./logs
c:

2. The Test Runner Script

We use a Bash script to orchestrate the build and test process. The core idea is to launch DOSBox-X in the background (so that the shell script can continue) and then use `xdotool` to interact with it.

Launching DOSBox-X

# Clean previous artifacts
mkdir -p target/screenshots
rm -rf target/screenshots/*

# Run DOSBox-X in the background
dosbox-x -conf dosbox-test.conf -c "program.exe" -c "exit" &
PID=$!

Automating Input with `xdotool`

`xdotool` is a powerful utility that lets you simulate keyboard input and mouse activity. We use it to send keystrokes to the DOSBox-X window.

# Wait for DOSBox to initialize
sleep 3

# Search for the window by title and send keys
# F12+p is the default DOSBox-X shortcut for taking a screenshot
xdotool search --name "MyGame-Test" key --window %@ F12+p

# Send 'q' to quit the game (if your game supports it)
xdotool search --name "MyGame-Test" key --window %@ q

# Ensure the process is dead
kill $PID || true

Verifying the Result

Once the game has run and a screenshot has been captured, we compare it against a reference image. ImageMagick’s compare tool comes quite handy as it returns a match score, which allows some wiggle room when screen shots don’t match perfectly.

if [ -f target/screenshots/f99_000.png ]; then
    # Use ImageMagick compare with PSNR metric.
    # compare writes the metric to stderr.
    # Output format is typically "inf" (perfect) or a float dB value.
    # We use awk to extract the first token to be safe against "val (norm)" formats.
    OUTPUT=$(compare -metric PSNR target/screenshots/f99_000.png tests/REFERENCE.png /dev/null 2>&1 || true)
    PSNR=$(echo "$OUTPUT" | awk -F'[()]' '{print $2}')

    # Check threshold (e.g. > 35 dB is usually good quality)
    # Use bc for float comparison
    if [ $(echo "$PSNR < 0.05" | bc -l) -eq 1 ]; then
        echo -e "Regression test ${GREEN}PASSED${NC} (PSNR: $PSNR)"
        exit 0
    else
        echo -e "Regression test ${RED}FAILED${NC}: screenshot mismatch (PSNR: $PSNR)"
        exit 1
    fi
else
    echo -e "${RED}Regression test FAILED${NC}: No screenshot generated"
    exit 1
fi

Conclusion

By combining DOSBox-X’s capture capabilities with Linux automation tools, we’ve created a fully automated regression test suite. This setup catches rendering bugs and logic errors before they are committed, bringing modern CI/CD confidence to retro game development.
